Brake Valve Assembly Test Fixture

DESCRIPTION

The Test Fixture for the Brake Valve Assembly provides the necessary components to mechanically support and actuate the valve. Also, facilitates the reading of displacements and force applied to the input lever during testing.

TECHNICAL INFORMATION

Load Capacity:             500 lbs


Overall dimensions
Length:                             27 in
Width:                               10 in
Height:                              5.15 in
Weight:                             32 lbs
